Fanless tablet for industry

The RUGGED Tab 8A is part of the spo-comm industrial tablets and completes the range at the entry level. . The tablet is equipped with a MediaTek Helio G99 CPU, 8GB RAM and a 128 GB eMMC SSD. The robust housing with passive cooling is paired with an extended temperature range and numerous extensions. This means that the system can be used in industry or logistics.

Integrated 5G module and optional accessories

The RUGGED Tab 8A is not only equipped with a fixed CPU, RAM and SSD, but also with an Android 12 operating system. In addition to a line-out connection, the tablet has a USB 2.0 port, two SIM card slots and a USB type C for charging and data transfer. Depending on the application, various accessories can be selected, including a 2D scanner, a backup battery or a docking station.

Highlights and technical data at a glance:

•     CPU: MediaTek Helio G99
•     GPU: ARM Mali-G57 MP2
•     RAM: 8 GB DDR4 Low Power
•     SSD: 128 GB eMMC
•     Operating system: Android 12
•     Dimensions (HxWxD): 20 mm x 155 mm x 236 mm
•     8″ IPS display, 5-point touch, 1200×900 resolution
•     Ambient conditions: -20°C up to +60°C at 10-90% non-condensing humidity
•     Passive cooling

Connectors:

•     1x USB 2.0
•     1x Line-Out
•     2x SIM
•     1x USB type C (charging & data transfer)
•     Integrated 4G / 5G module
•     Integrated GPS module

Configure your RUGGED Tab 8A

Industrial tablet with optional accessories

The RUGGED Tab 10 i5 is equipped with an Intel® Core i5-1235U CPU, 16 GB RAM and a 128 GB m.2 SSD equipped. The robust housing has space for the most important connections and can be supplemented with a wide range of accessories, such as a 2D scanner or a docking station. This makes the tablet the perfect companion in application areas that require high performance for demanding software, e.g. in construction site management and logistics.

Bridge battery, integrated WiFi, optional operating system

Despite its active cooling, the tablet has an extended temperature range of -20°C to +60°C and is dust and waterproof to IP65. The integrated bridge battery ensures that the time is bridged when the battery is changed and uninterrupted work is possible. The RUGGED Tab 10 i5 is already equipped with Wi-Fi and can be upgraded with either Windows 11 Pro or Windows 10 IoT. The display has a size of 10.1″ with a resolution of 1920×1200 pixels.

Highlights and technical data at a glance:

• CPU: Intel® Core™ i5-1235U (2x Performance Cores 1.3 GHz, max. 4.4 GHz and 8x Efficient Cores 0.9 GHz, max. 3.3 GHz)
• GPU: Intel® UHD graphics
• RAM: 16 GB DDR4
• SSD: 128 GB M.2 SSD
• Dimensions (HxWxD): 27 x 196 x 289 mm
• 10.1″ IPS display, 10-point touch, 1920×1200 resolution
• Ambient conditions: -20°C to +60°C at 10-90% non-condensing humidity
• Active cooling

Connectors:

• 1x mini HDMI 2.1a (max. 7680 x 4320 @ 60Hz (8K))
• 1x USB 3.2 Gen 1×1
• 1x Line-Out
• 1x microSD
• 1x SIM
• Integrated WiFi 6
• Integrated 4G / 5G module
• Integrated GPS module

Configure your RUGGED Tab 10 i5

3x 4K for digital signage applications

The ONE H610 is equipped with a powerful Intel® Core® i5-12400, 16GB RAM and a 512GB NVMe SSD. Thanks to its integrated Intel® UHD graphics unit, three video outputs (1x DisplayPort, 2x HDMI), which enable a maximum resolution of 4096×2160@60Hz (4K) on 3 screens, and the compact dimensions of just 36 x 180 x 180 mm (H x W x D), the system is perfect for use in price-sensitive digital signage applications where space is at a premium.

Optional equipment and connections for Thin Client

As is usual with spo-comm industrial PCs, the ONE H610 can also be optionally equipped with Windows 11 Professional and Windows 10 IoT. There is also the option of WiFi.

Despite its small dimensions, the housing of the ONE H610 offers an enormous variety of connections, including two audio ports (line-out and mic-in), a Kensington lock and a SIM card slot. A Gigabit LAN port and a total of 9x USB ports (4x USB 2.0, 2x USB 3.2 Gen 2×1, 2x USB 3.2 Gen 1×1, 1x USB 3.2 Gen 1×1 Type C) are also located on the housing and also enable use as a thin client.

Highlights and technical data at a glance:

•     CPU: Intel® Core™ i5-12400 (6x 2.5 GHz, max. 4.4 GHz)
•     GPU: Intel® UHD-Grafik 770
•     RAM: 16 GB DDR4
•     SSD: 512 GB M.2 NVMe
•     Max. Resolution: 4096×2160@60Hz (4K) on 3 screens
•     Dimensions (H x W x D): 36 mm x 180 mm x 180 mm
•     Active cooling
•     Ambient conditions: -0°C to +40°C at 10-90% non-condensing humidity

Connectors:

•     4x USB 2.0
•     2x USB 3.2 Gen 2×1
•     2x USB 3.2 Gen 1×1
•     1x USB 3.2 Gen 1×1 Type C
•     1x DisplayPort 1.2
•     2x HDMI 2.0
•     1x Gigabit LAN
•     2x audio port (MIC-IN, LINE-OUT)
•     1x Kensington Lock
•     1x SIM card slot
•     WiFi optional


Configure your ONE H610

ONE J6412 – Entry-level PC for industry

The ONE J6412 is a mini PC from our entry-level series, the ONE series, which is equipped with a passively cooled Intel Celeron J6412 processor, 8GB RAM and a 128GB eMMC SSD. Thanks to the COM RS232 interface and passive cooling, it is particularly suitable for industrial control applications. With integrated WiFi and compact dimensions of 30 x 116 x 107 mm, it also offers four USB 3.2 ports, a DisplayPort 1.2, HDMI 2.0, Gigabit LAN and two audio ports.

Key data:

• CPU: Intel® Celeron J6412, 4x 2 GHz
• RAM: 8 GB DDR4
• Ambient conditions: -0°C to +40°C at 10-90% non-condensing humidity

Discover the ONE J6412



RUGGED Q470E – Robustness meets versatility

Our RUGGED Q470E is ideal for classic industrial applications as well as for Industry 4.0 and automation. With dimensions of 242 x 240 x 85 mm, the housing offers numerous interfaces that are important for industry, including 4 COM ports, 8 USB ports (4x 3.0 and 4x 3.1 Gen 2) and 8 Gigabit LAN ports. The PC also has two SIM card slots and two audio connections. In addition to the Q470E, other PCs in our RUGGED series shine with their refinements.

Key data:

• CPU: Intel® Core® i5-10500TE, 6x 2.3 GHz (up to 3.7 GHz)
• Integrated wall bracket
• 8x Gigabit LAN
• Wide Range Power Input 9 – 60V

Discover the RUGGED Q470E



BRICK J3455E – fanless and robust

The BRICK J3455E is a passively cooled industrial PC in a robust metal housing measuring just 155 x 200 x 55 mm. This, and the extended temperature range of -10°C to +55°C, makes it ideal for use in demanding environments. It offers 6 COM ports, 6x USB, 2 LAN ports, as well as DisplayPort and HDMI for connecting monitors and other devices.

Key data:

• CPU: Intel® Celeron J3455E, 4 x 1.5 GHz up to 2.3 GHz
• Serial interfaces: 4x COM RS-232, 2x COM RS-232/422/485
• Wall bracket included, DIN rail bracket optional

Discover the BRICK J3455E



BRICK i3 7100U – all-rounder for industrial applications

The BRICK i3 7100U is the more powerful of our two BRICK models with its Intel® Core i3 7100U CPU, it supports up to 16 GB DDR4 RAM and 4K resolution on two screens. With its powerful performance, it has a low power consumption of just 15 watts and its robust metal housing makes it ideal for harsh environments. It also boasts an extended temperature range of -10° to +55°C. Connection options include 6 USB ports, 6x COM and two LAN interfaces, as well as optional WLAN. The BRICK is the right solution for various industrial applications – whether machine control, data measurement or control cabinet.

Key data:

• CPU: Intel® Core i3 7100U, 2 x 2.40 GHz
• 4x USB 3.2, 2x USB 2.0
• Independent image output on 2 screens

Discover the BRICK i3 7100U



Discover the entire product range of spo-comm Mini-PCs

Would you like to find out more about our Mini PCs? Do not hesitate to contact us!

Fanless industrial control computer

The ONE J6412 combines the eponymous Intel® Celeron® J6412 processor with 8GB RAM and a 128GB eMMC SSD. In contrast to the two other ONE systems H610 and i5, the ONE J6412 is passively cooled and can therefore – and because of its COM RS232 interface – be used as a low-cost computer for industrial control.

Integrated WiFi and small dimensions

The ONE J6412 comes with a fanless housing measuring just 30 x 116 x 107 mm (H x W x D). In addition to the COM port already mentioned, the Mini-PC has four USB 3.2 ports, one DisplayPort 1.2 and one HDMI 2.0. A Gigabit LAN and two audio ports can also be found on the housing.

Like all spo-comm Mini-PCs, the ONE J6412 can also be equipped with an optional operating system. WiFi is already integrated here, as is a VESA mount.

Highlights and technical data at a glance:

•     CPU: Intel® Celeron J6412 (4x 2 GHz, max. 2.6 GHz)
•     GPU: Intel® UHD graphics
•     RAM: 8 GB DDR4
•     SSD: 128 GB eMMC
•     Max. Resolution: 4096×2304@60Hz (4K) on 2 screens
•     Dimensions (H x W x D): 30 mm x 116 mm x 107 mm
•     Passive cooling
•     Ambient conditions: -0°C to +40°C at 10-90% non-condensing humidity

Connectors:

•     4x USB 3.2
•     1x DisplayPort 1.2
•     1x HDMI 2.0
•     1x Gigabit LAN
•     1x COM RS232
•     2x audio port (MIC-IN, LINE-OUT)

Configure your ONE J6412

Compact multi-monitor PC

The heart of the ONE i5 is the Intel® Core™ i5-1235U CPU, which is paired with 16GB RAM and a 512GB NVMe SSD. The compact housing (24 mm x 240 mm x 174 mm) offers three HDMI 2.0 ports and one DisplayPort 1.4, which enable content to be played in a resolution of 7680×4320@60Hz (8K). This makes the ONE i5 the perfect PC for multi-monitor applications.

HDMI-In for streaming and other connections

Thanks to the HDMI-in port, the system is also ideal wherever incoming video signals are processed, for example for all streamers and creative people.

The ONE i5 has a variety of ports, including one Gigabit and one 2.5 Gbps LAN port, as well as six USB 2.0, two USB 3.2 and one USB 3.1 Type C port. There are also two audio ports, a Kensington lock and a SIM card slot on the casing. As usual with the spo-comm Mini-PCs, the ONE i5 can be optionally equipped with an operating system and WiFi.

Highlights and technical data at a glance:

•     CPU: Intel® Core™ i5-1235U (2x Performance Cores 1.3 GHz, max. 4.4 GHz and 8x Efficient Cores 0.9 GHz, max. 3.3 GHz)
•     GPU: Intel® UHD graphics
•     RAM: 16 GB DDR5
•     SSD: 512 GB M.2 NVMe
•     Max. Resolution: 7680 x 4320 @ 60Hz (8K)
•     Up to 4 independent screens
•     Dimensions (H x W x D): 24 mm x 240 mm x 174 mm
•     Active cooling
•     Ambient conditions: -0°C to +40°C at 10-90% non-condensing humidity

Connectors:

•     6x USB 2.0
•     2x USB 3.2 Gen 2×1
•     1x USB 3.1 Gen 2×1 Type C
•     1x DisplayPort 1.4
•     3x HDMI 2.0
•     1x HDMI-In
•     1x Gigabit LAN
•     1x 2.5 Gbps LAN
•     2x audio port (MIC-IN, LINE-OUT)
•     1x Kensington Lock
•     1x SIM card slot
•     WiFi optional

Configure your ONE i5

2x DisplayPort for 4K digital signage

The CORE 3 is perfect for use as a digital signage player in environments where space is at a premium. At the heart of the housing, measuring just 36mm x 147mm x 165mm (H x W x D), is a powerful Intel® Core® i3-N305 processor with 8 efficiency cores with max. speed. 3.8 GHz. This is supported by up to 32 GB of DDR5 RAM and up to 2 TB of M.2 NVMe SSD, as well as the integrated Intel® UHD graphics unit. Thanks to the 2 DisplayPort 1.4a ports (optionally an additional one via USB C), content can be displayed in a resolution of 4K @ 60 Hz on 3 screens simultaneously.

Optional COM port, 2x LAN and extended temperature range

But the new system is not only suitable for DS applications. Our CORE 3 also feels right at home in industrial environments, such as industrial control applications. This is ensured by the extended temperature range of 0°C to +60°C, two LAN ports (1x 2.5 Gbps) and a COM RS232/422/485 connection.

Thin client and a total of 6x USB

The super-compact mini PC offers various connections for different applications. In addition to two audio ports (1x MIC-IN and 1x LINE-OUT) and a USB 3.2 Gen1 on the front panel of the CORE 3, there are four more USB ports (2x 3.2 Gen2, 2x 3.2 Gen1) on the back. As usual with spo-comm PCs, the CORE 3 can also be optionally equipped with Windows 11 Professional, Windows 10 IoT and Ubuntu. There is also the option for WiFi. For this reason, the CORE can also be used as a thin client.

Highlights and technical data at a glance:

•     CPU: Intel® Core® i3-N305 (8x Efficiency Core max. 3.8 GHz)
•     GPU: Intel® UHD graphics
•     RAM: up to 32 GB DDR5
•     SSD: up to 2TB M.2 NVMe
•     Max. Resolution: 4K @ 60Hz on 3 screens
•     Dimensions (H x W x D): 36mm x 147mm x 165mm
•     Ambient conditions: -0°C to +60°C at 10-90% non-condensing humidity

Connectors:

•     2x USB 3.2 Gen 2, 3x USB 3.2, 1x USB 3.2 Gen1 Type-C
•     2x DisplayPort 1.4a, 1x optional via USB Type C
•     1x Line-Out, 1x Mic-In
•     1x Gigabit LAN
•     1x 2.5 Gbps LAN
•     1x COM RS232/422/485
•     WiFi optional

Configure your CORE 3

It happened at a time in the spring of 2022…

… when Alex, one of our production employees, contacts CEO Michael Sporrer with a request. Both Alex and three of our other employees work as team leaders for the “High Octane Motorsports” club and were looking for sponsors for their latest project. The pitch of the project aroused inspiration and curiosity in the ranks of the company. Finally, Michael decided to sponsor a KUMO VI for the Octanes and the journey began.

More about the Octanes



The KUMO VI is on its way

Arriving at the Octanes in Erlangen, our KUMO embarks on a special journey. In the 22/23 season race car, our digital signage PC is responsible for supporting autonomous driving.

The KUMO is installed in the chassis behind the driver’s seat. A few changes had to be made so that it could be installed in this position and also make the best possible use of its performance. As the regulations require all calculations to take place in the vehicle, a new housing was produced for the KUMO VI, which must be waterproof and at the same time ensure good cooling. Among other things, the entire vehicle is subjected to a so-called “rain test”, which ensures that the sensitive innards in the vehicle remain dry even when used in pouring rain. The PC must also be secured in such a way that it remains in place despite the acceleration and centrifugal forces.



Ready, Set, Go – rollout in May 2023

At the beginning of May last year, the time had come – the rollout of the racing car was completed. Our trainees Patricia and Maxim had the honor of attending the event and watching the presentation of the FAUmax Pi. During the presentation, many exciting facts and sub-projects of the car were explained, as well as difficulties during production.

Finally, there was the opportunity to take a closer look at the FAUmax Pi, take pictures and, above all, ask questions. Here, our trainees had everything explained to them in detail by the team members who also work at spo-comm.



How will the journey continue?

The Octanes were at three events with their “Pi” in 2023 and, despite a few setbacks, were able to win some awards for their car. The Octanes were able to score points with creative refinements in the technical acceptance tests and some strengths were demonstrated. Driving did not go as planned at the beginning and there were a few obstacles along the way, but the team was able to develop their vehicle well over the course of the season.

As our employees are still active in the club and are interested in Formula Student, we remain in close contact and are always up to date with the latest news about the Octanes and our KUMO VI.  We have already been informed that our PC will also be used again in the new racing car for the 23/24 season. We are very excited to see what will change and how the journey will continue.

We would like to thank Alex for the great cooperation with the Octanes, which has always worked flawlessly, and we are looking forward to the Octanes’ upcoming season.



Discover our KUMO VI

Industrial-grade PC with customizable CPU

Both Panel PCs are equipped with an Intel® Celeron® 6305E CPU as standard, which can optionally be replaced by a more powerful Intel® Core™ i3-1115G4E processor. The CPU is supported by up to 32GB DDR4 RAM and an NVMe M.2 SSD with a capacity of up to 2TB supported. Thanks to the temperature range of 0°C to +50°C, a display with IP65 certification and a robust, passively cooled metal housing, the SQUARE 18 and SQUARE 21 undoubtedly deserve to be called industrial PCs.

2x DisplayPort for 8K resolution and LCD display

The highlight of the SQUARE models is the eponymous 10-point multi-touch LCD display. The 18.5″ version has a resolution of 1366 x 768 (WXGA) and the 21.5″ version has a resolution of 1920 x 1080 (FullHD). Thanks to the integrated Intel® UHD graphics unit and two DisplayPort 1.4 connections, two screens can be controlled, allowing content to be displayed in a resolution of 7680 x 4320 @ 60Hz – i.e. 8K.

Optional equipment and connections for the point of sale (PoS)

As is usual with our industrial PCs, the SQUARE 18 and 21 can also be optionally equipped with Windows 11 Professional and Windows 10 IoT. There is also the option of WiFi.

The Panel PCs have a variety of connections, including one Gigabit and one 2.5 Gbps LAN port, as well as four USB 3.2 Gen 2×1 ports and two COM RS232/422/485 ports. The latter enable the connection of external peripheral devices and thus also use at the point of sale.

Highlights and technical data at a glance:

•     CPU: Intel® Celeron® 6305E / Intel® Core™ i3-1115G4E
•     GPU: Intel® UHD graphics
•     RAM: up to 32 GB DDR4
•     SSD: up to 2TB M.2 NVMe
•     Max. Resolution: 7680 x 4320 @ 60Hz (8K) on 2 screens
•     SQUARE 18 Dimensions (H x W x D): 286.3mm x 465.2mm x 67.5mm
•     SQUARE 18: 18.5″ 10-point multi-touch LCD display, resolution 1366 x 768
•     SQUARE 21 Dimensions (H x W x D): 315.5 mm x 520.5 mm x 67.9 mm
•     SQUARE 21: 21.5″ 10-point multi-touch LCD display, resolution 1920 x 1080
•     IP65 (front) certified
•     Ambient conditions: -0°C to +50°C at 10-90% non-condensing humidity



Connectors:

•     4x USB 3.2 Gen 2×1
•     2x DisplayPort 1.4
•     1x Gigabit LAN
•     1x 2.5 Gbps LAN
•     2x COM RS232 / 422 / 485
•     WiFi optional

Configure your SQUARE 18

Configure your SQUARE 21
