-40ยฐC UP TO +70ยฐC
9V-48V POWER INPUT
FANLESS
VEHICLE-PCAs befits one of our RUGGED PCs, the T1000 model can also be expanded with numerous modules. In addition to a 4G module, this also includes a battery pack, which ensures that Windows shuts down properly. A GPS module and a PoE module are also available as options to adapt the system optimally to individual requirements.
The housing with dimensions of 95 x 260 x 250 mm offers space for a large number of connections. These include five video outputs (3x DisplayPort 1.2, 2x HDMI 2.0b), 10x RJ45 GbE LAN ports and three COM RS 232/422/485 ports. A total of 4 USB 3.2 Gen 1ร1 interfaces are available for connecting the system to other devices and exchanging data.
| System | |
|---|---|
| CPU | Intelยฎ Core i5-10500TE (FCLGA1200, 6 cores) |
| CHIPSET | Intelยฎ Q470E |
| GPU | NVIDIAยฎ Quadroยฎ T1000 Mobile
Intelยฎ UHD Graphics 630 |
| RAM | 16 GB SO-DDR4 (optional up to 64GB) |
| SSD / HDD | 512 GB M.2 PCIe 3.0 NVMe (optional up to 1TB)
2 x 2.5โณ SATA3 SSD/HDD |
| I/Os | |
|---|---|
| Front | 8 x LAN RJ45 GbE (Intelยฎ i210-AT)
2 x HDMI 2.0b // 4096ร2160@60Hz (MXM Graphics) 2 x SIM Card Socket 2 x 2.5โ Drive Bay for HDD / SSD (RAID 0,1,5) |
| Back | 3 x audio (Mic In, Line Out, Line In)
3 x DP 1.2 // 4096ร2340@60Hz (Intelยฎ GPU) 4 x USB 3.2 Gen1 Type A 2 x LAN RJ 45 GbE (Intelยฎ i210-AT + i219LM) 3 x COM RS 232/422/485 (CAN optional) 1 x GPIO (8 x DI & 4 x DO; COM optional) 1 x DC-IN Phoenix |
| Environment / Mass | |
|---|---|
| Dimensions (W x D x H) | 260mm x 250mm x 95mm |
| Ambient temperature (operation) | -40ยฐ-70ยฐC |
| Cooling | passive at 0.6 m/s air flow rate |
| Idle power consumption in W | 28 |
| Mounting bracket | Wall bracket (included) |
| Extensions | |
|---|---|
| M.2 | KeyM 2280 (occupied)
KeyB 3042 KeyA-E โ 2230 |
| mPCIe | 3 x |
| Miscellaneous | |
|---|---|
| Operating system | Windows 10 / 11 / Linux |
| PSU | optional; 9V โ 48V DC power input |
| Standards & Certificates | CE, FCC Class A, E-Mark, ECE R118, EN 50155, EN 45545-2 R25, MIL-STD-810G |
| Special features | In multi-GPU mode, the maximum independent resolution is 1920ร1200. |
| Class A warning | The device is intended for use in industrial environments. Operation of this device may cause radio interference in residential areas. |
| Warning for 802.11a use | If you want to use the WLAN module according to 802.11a in the 5 GHz range: Use in the 5150 MHz โ 5350 MHz frequency range is only permitted indoors! |
